Flex HS1

Low Cost
High Data Rate
Low Power Consumption
High Gain

Description

`Short-distance high-speed wireless point-to-point transmission base station (50 meters)`

1、Super high speed. The highest throughput can reach more than 2Gbps, extremely fast and stable transmission.

2、Economy. Registration-free and open ISM frequency bands, saving expensive spectrum licensing fees.

3、Less interference. Continuous and clean spectrum with limited interference.

4、Fully automatic. Plug and play, automatic alignment and connection, authentication and upload.

5、Small size. High integration and lightweight design, easy installation.

6、High gain. Phased array antennas and beamforming improve wireless performance.

7、Flexible networking. Support point-to-point, point-to-multipoint and other networking methods, flexible deployment.

Specification

Equipment Purpose	short distance transmission
Dimensions	80mm(L)65mm(W)20mm(H)
Weight	0.5KG
Transfer Mode	PTP/PTMP
Working Frequency	57GHz-66GHz
Channel Quantity	4
Transmission Distance	≤50m/2G±10%
Antenna Gain	12dBi
EIRP	≥37dBm
Beam Angle	±60°(horizontal)±60°(vertical)
Power Supply	DC(12V/2A) IEEE802.3af POE
Power Consumption	<6W
Standard	IP67
