Flex HS5

Low Cost
High Data Rate
Low Power Consumption
High Gain

Flex HS5

Description

Description

Long-distance high-speed wireless point-to-point transmission base station (1500M)

1、Super high speed. The highest throughput can reach more than 2Gbps, extremely fast and stable transmission.
2、 Economy. Registration-free and open ISM frequency bands, saving expensive spectrum licensing fees.
3、 Less interference. Continuous and clean spectrum with limited interference.
4、 Fully automatic. Plug and play, automatic alignment and connection, authentication and upload.
5、Small size. High integration and lightweight design, easy installation.
6、High gain. Phased array antennas and beamforming improve wireless performance.
7、Flexible networking. Support point-to-point, point-to-multipoint and other networking methods, flexible deployment.

Specification

Equipment Purpose long distance transmission
Dimensions 250mm(L)*180mm(W)*65mm(H)
Weight 1.2KG
Transfer Mode PTP/PTMP
Working Frequency 50GHz-70GHz
Channel Quantity 6
Transmission Distance 500m/1.8G
1000m/1.5G
Antenna Gain 23dBi
EIRP ≥45dBm
Beam Angle ±45°(horizontal)±45°(vertical)
Power Supply DC(12V/3A)
IEEE802.3af POE
Power Consumption <22W
Standard IP67
