Flex HS2
Low Cost
High Data Rate
Low Power Consumption
High Gain
Description
Description
Medium and short-distance high-speed wireless point-to-point transmission base station (200M)
1、Super high speed. The highest throughput can reach more than 2Gbps, extremely fast and stable transmission.
2、Economy. Registration-free and open ISM frequency bands, saving expensive spectrum licensing fees.
3、 Less interference. Continuous and clean spectrum with limited interference.
4、 Fully automatic. Plug and play, automatic alignment and connection, authentication and upload.
5、 Small size. High integration and lightweight design, easy installation.
6、High gain. Phased array antennas and beamforming improve wireless performance.
7、Flexible networking. Support point-to-point, point-to-multipoint and other networking methods, flexible deployment.
Specification
| Equipment Purpose | medium and short distance transmission |
| Dimensions | 185mm(L)*90mm(W)*45mm(H) |
| Weight | 0.8KG |
| Transfer Mode | PTP/PTMP |
| Working Frequency | 57GHz-66GHz |
| Channel Quantity | 4 |
| Transmission Distance | ≤200m/1G±20% |
| Antenna Gain | 17dBi |
| EIRP | ≥33dBm |
| Beam Angle | ±120°(horizontal)±20°(vertical) |
| Power Supply | DC(12V/1A) IEEE802.3af POE |
| Power Consumption | <12W |
| Standard | IP65 |
