Flex HS4

Low Cost
High Data Rate
Low Power Consumption
High Gain

Description

`Medium and short-distance high-speed wireless point-to-point transmission base station (150M)`

1、Super high speed. The highest throughput can reach more than 2Gbps, extremely fast and stable transmission.

2、 Economy. Registration-free and open ISM frequency bands, saving expensive spectrum licensing fees.

3、 Less interference. Continuous and clean spectrum with limited interference.

4、 Fully automatic. Plug and play, automatic alignment and connection, authentication and upload.

5、 Small size. High integration and lightweight design, easy installation.

6、High gain. Phased array antennas and beamforming improve wireless performance.

7、▎Flexible networking. Support point-to-point, point-to-multipoint and other networking methods, flexible deployment.a

Specification

Equipment Purpose	medium and short distance transmission
Dimensions	250mm(L)180mm(W)65mm(H)
Weight	1.2KG
Transfer Mode	PTP/PTMP
Working Frequency	50GHz-70GHz
Channel Quantity	4
Transmission Distance	150m/1.2G
Antenna Gain	18dBi
EIRP	≥37dBm
Beam Angle	±40°(horizontal)±40°(vertical)
Power Supply	DC(12V/3A) IEEE802.3af POE
Power Consumption	<15W
Standard	IP67
